Monacor HT-30 Spare Part For Loudspeaker

Miniature PA horn tweeter Monacor HT-30 with dimensions 67 x 67 x 47 mm. This tweeter provides linear and wide bandwidth reproduction. It also offers high power capability due to ferrofluid.

Technical specs:

• Impedance (Z): 8 Ω
• Frequency range: fx-20 kHz
• Resonant frequency (fs): 2 kHz
• Rec. crossov. frequ. (fmax.) (12 dB/oct.): 5 kHz
• Power rating (RMS): 50 W
• Peak music power output (MAX): 100 W
• Sensitivity: 98 dB/W/m
• Voice coil diameter: Ø 12 mm
• Magnet diameter: Ø 50 mm
• Mounting cutout: Ø 59 mm
• Mounting depth: 45 mm
• Dimensions: 67 x 67 x 47 mm
• Width: 67 mm
• Height: 67 mm
• Depth: 47 mm
• Admiss. ambient temp.: 0-40 °C
• Weight: 0.18 kg
• Packing unit: 1
